X SERIES TRANSMITTERS

X-Series-Transmitters pipeline pig apache pipeline products

The X300-2C and X300-2C-BH are TRAXALL compatible electromagnetic transmitters which have both programmable frequency and power control through CDI’s proprietary FieldLink wireless communications system. X300-2C-BH is an end-flanged version of the X300-2C baseline transmitter.

Less than 2″ x 1″, the X100-1N is the world’s smallest electromagnetic pipeline transmitter, yet is a fully-capable TRAXALL-compatible pig-tracking device offering both programmable frequency and power control.

The X100-2N is designed to fit inside the smallest 2 and 8 inch pipeline pigs, the X100-2N’s rugged stainless steel housing is compatible with hydrocarbons, ammonia and most cleaning chemicals found in pipelines.

Designed for Subsea 7, the X100-2N-SWX is designed to fit inside 6 through 12 inch pipeline pigs, the X100-2N-SWX’s rugged stainless steel housing is compatible with hydrocarbons, ammonia and most cleaning chemicals found in pipelines.

Designed as a special-use transmitter for very small pigs and pipelines with tight radius bends, the X100-2N-RC remains inactive until manually started by removing its ripcord pin with a strong pull from outside the pipeline.

Compare:

Click to Enlarge

X-Series Transmitter

LINE SIZES PRESSURE (PSI) MODEL
2" - 6" 2,500 X100-1N
2" - 8" 2,500 X100-2N
2" - 8" 2,500 X100-2N-SWX
2" - 8" 2,500 X100-2N-RC
6" - 12" 2,500 X300-2C
6" - 12" 2,500 X300-2C-BH
12" - 36" 2,500 X400-3D
